Camera

Image Sensor:

|

1/3" Progressive Scan CMOS

Min. Illumination:

|

0.01Lux @(F1.2,AGC ON), 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR

Shutter time:

|

1/3 s ~ 1/100,000 s

Slow shutter:

|

Support

Lens:

|

2.8 - 12 mm @ F1.4, motorized lens (-Z), angle of view: 112°~33.8°

Lens Mount:

|

φ14

Adjustment Range:

|

Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355°

Day& Night:

|

IR cut filter with auto switch

Wide Dynamic Range:

|

120 dB

Digital noise reduction:

|

3D DNR

Compression Standard

Video Compression:

|

H.264/MJPEG/H.264+

H.264 code profile:

|

Main Profile

Video bit rate:

|

32Kbps~16Mbps

Audio Compression:

|

-S: G.711/G.722.1/G.726/MP2L2


Max. Image Resolution:

|

2688 × 1520

Frame Rate:

|

50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720)
60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720)

Image Enhancement:

|

BLC/3D DNR/ROI

Image Settings:

|

Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser

Day/Night Switch:

|

Auto/Schedule/Triggered by Alarm In

Network

Network Storage:

|

Micro SD/SDHC/SDXC card with ANR (up to 128G), NAS (Support NFS, SMB/CIFS)

Alarm Trigger:

|

Face Detection,Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception

Protocols:

|

TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour

General Function:

|

One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering

System Compatibility:

|

ONVIF (Profile S, Profile G),ISAPI

Interface

Communication Interface:

|

1 RJ45 10M / 100M Ethernet interface

General

Operating Conditions:

|

-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)

Power Supply:

|

12 VDC ± 25%, PoE (802.3af Class3)

Power Consumption:

|

Max. 5.5 W

Impact Protection:

|

IEC60068-2-75Eh, 50J; EN50102, IK10

Weather Proof:

|

IP67

IR Range:

|

Up to 30m

Dimensions:

|

Φ 140 × 99.9 mm (Φ 5.51” × 3.94”)

Weight:

|

1000g (2.20lbs)

NOTE：:

|

* “-S” series support 1-ch audio I/O and 1-ch alarm I/O
