Networking Protocol IPV4, ARP, TCP, UDP, ICMP DHCP Client NTP Client (D-Link) DNS Client DDNS Client (Dyndns and D-Link) SMTP Client FTP Client HTTP Server PPPoE UPnP Port Forwarding LLTD Built-In Protocol 10/100 BASE-TX Fast Ethernet 802.11b/g/n WLAN Wireless Connectivity 802.11b/g/n Wireless with WEP/WPA/WPA2security WPS Wireless Transmit Output Power (Typical) 11b - 16 dbm 11g/11n - 12 dbm SDRAM 64 MB Flash Memory 8 MB Reset Button Reset to factory default Video Codecs H.264 MJPEG JPEG for still images Video Features Adjustable image size and quality Time stamp and text overlay Flip and Mirror Resolution 640 x 480 at up to 30 fps 320 x 240 at up to 30 fps 160 x 112 at up to 30 fps Lens Focal length: 2.2 mm, F2.0 IR LED 8 meter illumination distance with 10 LEDs and light sensor Viewing Angle Horizontal: 66.2° Vertical: 49.08° Diagonal: 77.04° Pan/Tilt Range Pan Range: +170° ~ -170° (Total 340°) Tilt Range: +95° ~ -25° (Total 120°) Digital Zoom Up to 4x 3A Control AGC (Auto Gain Control) AWB (Auto White Balance) AES (Auto Electronic Shutter) Power Input: 100-240 V AC, 50/60 Hz Output: 12 V DC, 1 A Dimensions Camera Only - 102.35 x 101.27 x 133.6 mm(4.03 x 3.99 x 5.26 inches) Camera Including Mounting Bracket -102.35 x 101.27 x 230.0 mm(4.03 x 3.99 x 9.06 inches) Max Power Consumption 8.64W Operation Temperature 0 ˚C to 40 ˚C (32 ˚F to 104 ˚F) Storage Temperature -20 ˚C to 70 ˚C (-4 ˚F to 158 ˚F)
